TQ-3A Hydrocarbon Analyzer

Performance features:

The absorption method is used to determine the carbon and hydrogen content in coal or other organic materials. It features a three-stage independent automatic constant temperature control system, allowing flexible temperature settings and adjustments. The digital temperature display provides clear and accurate readings, ensuring stable and reliable performance. The system supports simultaneous testing of two samples. The overall design is rational, with an aesthetically pleasing appearance, user-friendly operation, and excellent maintainability.

Technical parameter:

Measurement range: Carbon (1-100%) and Hydrogen (0-20%). The accuracy meets the requirements of GB/T476-2008.
Temperature measurement accuracy: Class 0.2 | Temperature range: (100-1100)℃ | Temperature control accuracy: ±10℃
Single-section furnace with a combustion chamber temperature of 850°C, rated power of 1200W, and a constant temperature zone length of 60mm.
The second section furnace has a furnace temperature of 800℃, a rated power of 1500W, and a constant temperature zone length of 80mm.
The three-section furnace has a combustion chamber temperature of 600°C and a rated power of 800W.
Power supply: AC220V ±22V,50Hz ±1Hz
Dimensions (mm): 1200×350×450
Weight: 53 kg
