Main features:
1. The color Chinese touch screen display is controlled by a high-speed signal processor.
2. The system employs an adaptive PID control algorithm to automatically adjust the temperature rise curve according to standard specifications.
3 Differential detection with automatic system deviation correction, and automatic stop with alarm when temperature exceeds the limit;
4. The automatic determination of mixing, ignition, detection, alarm, cooling and printing instruments is completed;
5. Data storage capability: 2000 data entries can be stored, with historical records accessible at any time.
The key technical indexes:
Display mode: 10-inch color touchscreen
Measuring method: differential detection of thermocouple
Measurement range: room temperature to 400℃
Repeatability: flash point ≤150℃ with an error margin of ±4℃; flash point>150℃ with an error margin of ±8℃
Resolution: 0.1℃
Rapid heating speed: in accordance with GB/T3536 standard
Printers: Low energy consumption high speed thermal printer, 56 mm paper width
Ignition method: Select from gas ignition or electronic ignition
Temperature Detection:German Precision Platinum Resistance
Self-check functions: printer, igniter, solenoid valve, detection arm lifting, and ignition rod sweeping.
Operating environment: Temperature 10℃-45℃, humidity 30-80%
Dimensions: 400×300×240mm
Power supply: AC220V±10%
Weight: about 15 kg
