Main features
1. The unique design concept enables the same element to measure both low and high content of materials on the same instrument, which is unique to the current similar and identical instruments.
2. The instrument can store 10 primary curves (measuring range of 5% ~ 7% of the width) and 6 secondary curves (measuring range of about 15% of the width), so that users can detect more material varieties and a wider measuring range.
3. When the instrument spectral peak position drifts, it can be corrected through the instrument touch screen, and the user does not need to open the instrument cover for adjustment.
4. Similar instruments have long used upward-probing sample structures (with samples positioned above the detector), which often caused sample powder to fall onto the detector during operation, compromising accuracy. Some manufacturers 'compacted samples were prone to cracking, leading to chunky debris that damaged expensive detectors and rendered instruments unusable. Our instrument's downward-probing design (with samples positioned below the detector) effectively prevents such structural flaws from causing unnecessary user losses.
5. The instrument background automatically checks a series of important data of the instrument, such as measurement position, set parameters, and energy spectrum peak position. If there is an abnormality, the instrument will issue an abnormality prompt dialog window to remind the user of the problem in advance.
6. The rapid analysis enables precise measurement of CaO%, Fe2O3%, SiO2%, Al2O3%, and SO3% in materials within just 90 seconds.
7. The instrument automatically loads and unloads samples without requiring staff supervision! It eliminates the "primitive" manual operation mode where operators had to manually load samples and recall the sliding tray after testing. Designed for dusty environments, its unique mechanical structure and anti-dust contamination features ensure nearly silent operation with smooth sample handling.
8. No chemical reagents, no waste discharge, no radioactive sources, low power consumption, in line with the requirements of environmental protection and energy saving.
9. Equipped with the latest touch screen LCD display and industrial control board, it offers extensive programmable development space and supports remote upgrades via the device's USB port.
10. All test data can be queried and printed, which is very convenient to use.
Technical indicators:
1.Analysis range: CaO%, Fe2O3%, SiO2%, Al2O3%, SO3%:0.01% to over 90%;
2.Analysis width: The maximum and minimum percentage values of CaO%, Fe2O3%, SiO2%, Al2O3%, and SO3% should be ≤15%. The operating range is determined by calibrating the working curve.
3.Analysis accuracy: Standard deviation CaO% ≤0.05%, Fe2O3% ≤0.04%, SiO2% ≤0.07%, Al2O3% ≤0.07%, SO3% ≤0.04%.
4.Analysis duration: n * 90 seconds (n = 1, 2, 3, 4, 5, typically n = 2);
5.Operating conditions: AC200V~240V,50Hz; ≤30W; ambient temperature 5~40℃; relative humidity ≤85% (30℃)
6. Size and weight: 420mm * 285mm * 195mm, 10kg.
