Features of the instrument
1. The instrument adopts large capacity single chip microcontroller control, stable and reliable operation;
2. The instrument has the function of temperature, humidity and clock display, and can customize infrared oil temperature measurement.
3. The instrument has a wide range watchdog circuit to eliminate the phenomenon of system crash;
4. Multiple standard selection, the instrument program has GB/T507-1986, GB/T507-2002, DL429.9, IEC156 and self-programming operation, can adapt to different users' multiple choices;
5. The oil cup of the instrument is processed with special glass and polymer materials to prevent oil leakage and corrosion;
6. The unique high-voltage sampling design of the instrument allows the test value to directly enter the A/D converter, avoiding the error caused in the analog circuit, so that the measurement result is more accurate;
7. The instrument has the function of overcurrent, overvoltage, short circuit and other protection functions, and has a strong anti-interference ability and good electromagnetic compatibility;
8. You can switch between Chinese and English to meet the needs of any customer;
9. The instrument itself has the function of data analysis to assist the staff to determine the quality of oil;
Technical indicators
1. The capacity of the booster is 1.5 kVA
2. Boost speed 0.5kV/s-5.0kV/s (increasing by 0.5) + optional
Error: 0.2kV/s
3. Output voltage 0-100 kV (optional)
4. Voltage accuracy (2% reading +2 characters)
5. Power distortion rate is less than 1%
6. The electrode gap shall be 2.5mm
7. Number of tests: 6 (optional 1-9)
8. Set time 900S (0-9000 S optional)
9. Interval rest time 300S (0-900 S optional)
10. Stir for 15S (0-250S optional)
11. Dimensions 650mm×470 mm×410 mm
