Instrument features
1. The instrument adopts large capacity single chip microcomputer control, stable and reliable operation;
2. The instrument has the function of temperature, humidity and clock display, and can customize infrared oil temperature measurement.
3. The wide range watchdog circuit is built into the instrument to eliminate the phenomenon of system crash;
4. Multiple standard selection, the instrument program has GB/T507-1986, GB/T507-2002, DL429.9, IEC156 and self-programming operation, can adapt to different users for a variety of choices;
5. The instrument oil cup is made of special glass and polymer materials, which are finely processed to prevent oil leakage and corrosion;
6. The unique high-voltage sampling design of the instrument allows the test value to directly enter the A/D converter, avoiding the error caused in the analog circuit, so that the measurement results are more accurate;
7. The instrument has the function of overcurrent, overvoltage, short circuit and other protection functions, and has a strong anti-interference ability and good electromagnetic compatibility;
8. You can switch between Chinese and English at will to meet any customer needs;
9. The instrument has its own data analysis function to assist the staff to determine the quality of oil;
10. Data transfer 232;
Technical indicators
1. The capacity of the booster is 1.5 kVA
2. Boost speed 0.5kV/s-5.0kV/s (increasing by 0.5) + optional level
Error 0.2kV/s
3. Output voltage 0-80 kV (optional)
4. Voltage accuracy (2% reading +2 characters)
5. Power distortion rate <1%
6. The electrode gap shall be 2.5mm standard
7. Number of tests: 6 (option 1-9)
8. Set time: 900S (optional 0-9999S)
9. Interval rest time 300S (0-999S optional)
10. Stir time 15S (0-999S optional)
11. External dimensions 410mm × 380mm × 370mm
12. Weight: 35kg 12. Weight: 35kg
