Main functions and features
4.3-inch TFT true color touch screen, resolution 480×272, user-friendly and easy to use.
Using 32-bit microprocessor as the main control core, a new generation of intelligent operating system.
PID temperature control, precise control of constant temperature funnel temperature.
Using built-in oil-free maintenance-free vacuum pump, programmed control of pressure reduction filtration.
The unique design of the vacuum pump structure, even if the oil sample is sucked into the vacuum pump will not damage the instrument, reduce accidental loss.
The compact structure occupies only 15% more space than A4 paper.
Technical indicators
1. Method adopted: GB/T 511-2010 "Determination of mechanical impurities in petroleum, petroleum products and additives"
2. Display: 4.3 inch LCD display (LCD), resolution 480×272
3. Temperature control range: room temperature ~100℃
4. Temperature control accuracy: ±1℃
5. Resolution: 0.1℃
Rated power: 240 W
7. Dimensions: 240×300×400 (unit mm, excluding the foot pad)
8. Weight: 5 kg
Conditions of use
1. Environmental temperature: 5℃~40℃
2. Relative humidity: <80%
3, input power supply: AC220V±10V 50Hz
